Features

This well-designed handheld contact type linear imager scanner has inherited the characteristic of “high performance with low price” from its previous series. Aside from the principle of excellence mechanical design, it also installs with many user-friendly operations; detachable cable, 4-in-1 interface, and 2 years product warranty; these have added-up additional values to it. As far as the performance, this scanner provides reliable scanning depth from contact to 50mm, collaborating with POS or regular cash register system, user is able to program this device to “continuous mode ” or any other scan mode if needed, Aid in various major barcodes, hand-on software-programming function, this economical-type barcode scanner is the best choice ever.

  • Contact type linear imager bar code scanner.
  • Contact read 80mm bar code at window.
  • Ideal resolution for retail and general commercial applications.
  • Reads most 1D bar code symbologies include GS1 Databar codes.
  • Compatible with most host systems through "all-in-one" universal interface.
  • Folio style and ergonomic design, available for Beige and Black color choice.
  • 1D Codes
  • GS1
  • SD320

    SD320
  • Compare to

Tech Specs

Environmental

Ambient light
Up to 20,000 Lux Max
- Up to 10,000 Lux Max - 100,000 Lux Max. Up to 5,000 Lux Max Up to 20,000 Lux Max

Specifications

Dimension(WxDxH) Light Source Depth of Field Resolution Scan Rate Indicators Drop Resistance Print Contrast Ratio Width of Field
173.5 x 90 x 56.2mm 632±5nm Red LED Contact to 50mm@20mil/0.5mm, PCS90%, Code39 4mil/0.1mm 120 scans Beeper and LED 1.2m 30% 90mm (80mm at window)
- 168 x 65 x 54.9mm 73.50 mm W x 173 mm D x 76.2 mm H 73.5 mm W x 76.2mm H x 173 mm L 166.4 x 78 x 77.8mm 171.3 x 82.8 x 75mm - 632±5nm Red LED Visible Red light 635nm ±5nm LED Visible Red light 635±5nm LED 632±5nm Red LED 632±5nm Red LED - Contact to 200mm@20mil/0.5mm, PCS90%, Code39 Up to 550mm@20mil/0.5mm, PCS90%, Code39 Up to 550mm@20mil/0.5mm, PCS90%, Code39 Contact to 60mm@20mil/0.5mm, PCS90%,Code39 Contact to 80mm@20mil/0.5mm, PCS90%,Code39 - 4mil/0.1mm 4mil/0.1mm@PCS90%, Code39 4mil/0.1mm@PCS90%, Code39 4mil/0.1mm 3mil/0.076mm - 100 scans±10% Horizontal: 45° Smart detection, up to 500 scans per second 120 scans 200 scans±10% - Beeper Beep and LED (Good read Green) Beep and LED (Good read Green) Beeper Beeper and LED - 1.5m 70.86 inches(180cm) drop on concrete surface 59.05 inches(150cm) drop on concrete surface 1.2m 1.2m - 25% 25% 25% 30% 30% - 90mm (40mm at window) - - 80mm (60mm at window) 90mm (80mm at window)

Electrical Characteristics

Interface Power
RS232, USB(HID,Virtual COM),KBW DC 5V
- RS232, USB(HID,Virtual COM),KBW RS232, USB (HID, Virtual COM) RS232, USB (HID, Virtual COM), KBW RS232, USB(HID,Virtual COM),KBW RS232, USB(HID,Virtual COM),KBW - DC 5V DC 5V DC 5V DC 5V DC 5V
Configuration Guide Configuration Quick Guide Datasheet Driver-OPOS Driver-Virtual COM E-Catalogue Specification
Download Download Download Download Download Download Download

Accessories

  1. Adaptor-5V(180 degree)

    • Adaptor-5V(180 degree)
    • P/N0104-SP00081
    • RemarkSwitch Power Adaptor 90-264V 5V/2A DC Plug 180 degree
    • Color-
  2. Cable-CHK-PS/2(Beige)

    • Cable-CHK-PS/2(Beige)
    • P/N0114-2150111
    • RemarkKeyboard wedge/PS2 interface cable, MD6F+MD6M+RJ45 10P straight cable Beige color length 1.5m
    • ColorBeige
  3. Cable-CHK-PS/2(Black)

    • Cable-CHK-PS/2(Black)
    • P/N0114-2150121
    • RemarkKeyboard wedge/PS2 interface cable, MD6F+MD6M+RJ45 10P straight cable Black color length 1.5m
    • ColorBlack
  4. Cable-CHK-RS232(Chip, Beige)

    • Cable-CHK-RS232(Chip, Beige)
    • P/N3114-5801131
    • RemarkRS232 Interface cable, DB9F Moldin Head With PCB +DC-Jack+RJ45 10P straight cable Beige color length 1.5m
    • ColorBeige
  5. Cable-CHK-RS232(Chip, Black)

    • Cable-CHK-RS232(Chip, Black)
    • P/N3114-5801141
    • RemarkRS232 Interface cable, DB9F Moldin Head With PCB +DC-Jack+RJ45 10P straight cable Black color length 1.5m
    • ColorBlack
  6. Cable-CHK-USB(Beige)

    • Cable-CHK-USB(Beige)
    • P/N0114-980A131
    • RemarkUSB Interface cable, USB A TYPE RJ45 straight Beige color length 1.5m
    • ColorBeige
  7. Cable-CHK-USB(Black)

    • Cable-CHK-USB(Black)
    • P/N0114-980A231
    • RemarkUSB Interface cable, USB A TYPE RJ45 straight Black color length 1.5m
    • ColorBlack
  8. Stand-300 Series(Holder, Beige)

    • Stand-300 Series(Holder, Beige)
    • P/N0121-CH02011
    • RemarkPlastic Holder for SG3xx/LG3xx/IG3xx Series
    • ColorBeige
